85℃ 5000hours

◆specific ations

items	characteristics
category temperature range	-25~ 85℃
rated voltage range	6.3~550vdc
capacitance tolerance	± 20%（m）                                                                                                               at  20℃/120hz
leakage current	i=0.02cv or 5ma,whichever is smaller i: where, i : max. leakage current（µa）、c: nominal capacitance（µf）、rated voltage (v)at 20℃after 5 minutes)
dissipation factor（tanδ）	≤0.25                                                                                                                    at  20℃/120hz
low temperature characteristics	capacitance change(vdc) c（-25℃）/c（ 20℃）≥0.7                                                                       at  20℃/120hz
insulation resistance	when measured between the terminals that are connected to each other and to the mounting clamp on the insulating sleeve covering the case by using an insulation resistance meter of 500vdc, the insulation resistance shall not be less than 100mω
insulation withstanding voltage	when a voltage of 2,000vac is applied for 1 minute between the terminals that are connected to each other and to the mounting clamp on the insulating sleeve covering the case, there shall not be electrical damage
endurance	the following specifications shall be satisfied when the capacitors are restored to 20℃ after subjected to dc voltage with the rated ripple current is applied (the peak voltage shall not exceed the rated voltage) for 5,000 hours at 85℃
	capacitance change	≤±20% of the initial value
	d.f. (tanδ)	≤300% of the initial specified value
	leakage current	≤the initial specified value
shelf life	the following specifications shall be satisfied when the capacitors are restored to 20℃ after exposing them for 1000 hours at 85℃ without voltage applied. before the measurement, the capacitor shall be preconditioned by applying voltage according to item 4.1 of jis c 5101-4
	capacitance change	≤±20% of the initial value
	d.f. (tanδ)	≤300% of the initial specified value
	leakage current	≤the initial specified value

srandrad ratings

rated voltage ur [v] rated cap.cr [μf] case size d x l [mm] typ.esr 100 hz, 20°c [mω] ripple current ir~100 hz,85℃[a] order code 6.3v 8sv 28000 35*40 46.9 4.1 lnb6r3m5b283ka40 57000 35*55 26.5 6.1 lnb6r3m5b573ka55 68000 35*65 18.8 7.8 lnb6r3m5b683ka65 91000 35*80 14.7 9.4 lnb6r3m5b913ka80 100000 35*55 18.8 8.8 lnb6r3m5b104ka55 110000 35*90 12.8 11.2 lnb6r3m5b114ka90 120000 35*65 14.3 11.0 lnb6r3m5b124ka65 130000 35*105 11.0 13.0 lnb6r3m5b134kaa5 130000 50*55 14.2 11.9 lnb6r3m5b134kc55 150000 50*65 9.9 11.6 lnb6r3m5b154kc65 160000 35*115 9.8 12.5 lnb6r3m5b164kab5 160000 35*80 11.0 12.6 lnb6r3m5b164ka80 180000 35*130 8.9 14.7 lnb6r3m5b184kad0 200000 35*140 8.3 16.0 lnb6r3m5b204kae0 200000 35*90 9.1 15.9 lnb6r3m5b204ka90 210000 50*80 7.8 17.8 lnb6r3m5b214kc80 240000 35*105 7.9 18.3 lnb6r3m5b244kaa5 260000 50*90 6.5 15.6 lnb6r3m5b264kc90 260000 65*65 6.9 16.2 lnb6r3m6c264kd65 280000 35*115 7.0 17.1 lnb6r3m5b284kab5 310000 50*105 5.6 20.2 lnb6r3m5b314kca5 320000 35*130 6.4 19.7 lnb6r3m5b324kad0 350000 65*80 5.3 22.6 lnb6r3m6c354kd80 360000 35*140 6.0 22.0 lnb6r3m5b364kae0 370000 50*115 5.0 24.9 lnb6r3m5b374kcb5 420000 50*130 4.5 23.0 lnb6r3m5b424kcd0 440000 65*90 4.3 25.0 lnb6r3m6c444kd90 470000 50*140 4.2 26.7 lnb6r3m5b474kce0 520000 76*80 4.1 28.3 lnb6r3m6c524ke80 530000 65*105 3.8 30.4 lnb6r3m6c534kda5 610000 65*115 3.4 33.4 lnb6r3m6c614kdb5 650000 76*90 3.3 34.6 lnb6r3m6c654ke90 700000 65*130 3.1 33.3 lnb6r3m6c704kdd0 780000 76*105 2.9 35.7 lnb6r3m6c784kea5 790000 65*140 2.8 37.9 lnb6r3m6c794kde0 910000 76*115 2.6 41.0 lnb6r3m6c914keb5 1000000 76*130 2.4 44.4 lnb6r3m6c105ked0 1100000 76*140 2.4 45.0 lnb6r3m6c115kee0 1100000 89*150 3.0 41.4 lnb6r3m6c115kfa5 1200000 76*146 2.4 51.5 lnb6r3m6c125kee6 1200000 89*115 2.6 43.2 lnb6r3m6c125kfb5 1400000 89*130 2.4 47.1 lnb6r3m6c145kfd0 1600000 76*192 2.4 49.3 lnb6r3m6c165kek2 1600000 89*140 2.4 47.9 lnb6r3m6c165kfe0 1700000 89*146 2.4 49.4 lnb6r3m6c175kfe6 1900000 76*218 2.4 49.9 lnb6r3m6c195ken8 2300000 89*192 2.4 54.1 lnb6r3m6c235kfk2 2700000 89*218 2.4 56.5 lnb6r3m6c275kfn8 10v 12sv 24000 35*40 46.9 4.1 lnb010m5b243ka40 44000 35*55 26.5 6.1 lnb010m5b443ka55 57000 35*65 26.5 6.1 lnb010m5b573ka65 76000 35*80 15.5 9.2 lnb010m5b763ka80 79000 35*55 18.8 8.8 lnb010m5b793ka55 96000 35*90 12.8 11.2 lnb010m5b963ka90 100000 35*65 14.3 11.0 lnb010m5b104ka65 100000 50*55 17.6 10.3 lnb010m5b104kc55 110000 35*105 11.0 13.5 lnb010m5b114kaa5 130000 35*115 9.8 10.3 lnb010m5b134kab5 140000 35*80 11.0 11.8 lnb010m5b144ka80 140000 50*65 13.4 11.4 lnb010m5b144kc65 150000 35*130 8.9 14.7 lnb010m5b154kad0 170000 35*140 8.3 16.0 lnb010m5b174kae0 170000 35*90 9.1 15.9 lnb010m5b174ka90 180000 50*80 10.5 15.4 lnb010m5b184kc80 210000 35*105 7.9 18.3 lnb010m5b214kaa5 220000 50*90 8.7 13.5 lnb010m5b224kc90 220000 65*65 8.8 14.4 lnb010m6c224kd65 240000 35*115 7.0 17.1 lnb010m5b244kab5 270000 50*105 7.5 17.4 lnb010m5b274kca5 280000 35*130 63.4 19.7 lnb010m5b284kad0 290000 65*80 6.7 20.0 lnb010m6c294kd80 310000 35*140 6.0 22.0 lnb010m5b314kae0 310000 50*115 6.7 21.5 lnb010m5b314kcb5 350000 50*130 6.1 19.8 lnb010m5b354kcd0 370000 65*90 5.5 22.1 lnb010m6c374kd90 400000 50*140 5.7 22.9 lnb010m5b404kce0 430000 76*80 4.1 28.3 lnb010m6c434ke80 440000 65*105 4.8 26.9 lnb010m6c444kda5 510000 65*115 4.3 29.5 lnb010m6c514kdb5 540000 76*90 3.3 34.6 lnb010m6c544ke90 590000 65*130 3.9 29.5 lnb010m6c594kdd0 640000 76*105 2.9 35.7 lnb010m6c644kea5 660000 65*140 3.6 33.5 lnb010m6c664kde0 750000 76*115 2.6 41.0 lnb010m6c754keb5 860000 76*130 2.4 44.4 lnb010m6c864ked0 900000 89*105 2.9 41.6 lnb010m6c904kfa5 940000 76*140 2.3 47.1 lnb010m6c944kee0 1000000 76*146 2.3 52.8 lnb010m6c105kee6 1000000 89*115 2.8 42.0 lnb010m6c105kfb5 1200000 89*130 2.5 46.3 lnb010m6c125kfd0 1300000 89*140 2.2 50.3 lnb010m6c135kfe0 1400000 76*192 2.1 52.7 lnb010m6c145kek2 1400000 89*146 2.1 52.7 lnb010m6c145kfe6 1600000 76*218 2.1 54.2 lnb010m6c165ken8 1900000 89*192 1.8 64.3 lnb010m6c195kfk2 2200000 89*218 1.5 70.6 lnb010m6c225kfn8                       16v 20sv 21000 35*40 46.9 4.1 lnb016m5b213ka40 35000 35*55 26.5 6.1 lnb016m5b353ka55 49000 35*65 20.1 7.5 lnb016m5b493ka65 57000 35*55 18.8 8.3 lnb016m5b573ka55 62000 35*80 15.5 9.7 lnb016m5b623ka80 73000 50*55 17.6 9.5 lnb016m5b733kc55 76000 35*90 12.8 11.7 lnb016m5b763ka90 77000 35*65 15.3 11.1 lnb016m5b773ka65 90000 35*105 11.0 13.5 lnb016m5b903kaa5 99000 35*115 9.8 11.6 lnb016m5b993kab5 100000 35*80 12.5 11.1 lnb016m5b104ka80 110000 35*130 8.9 14.0 lnb016m5b114kad0 110000 50*65 13.4 12.0 lnb016m5b114kc65 130000 35*140 8.3 16.0 lnb016m5b134kae0 130000 35*90 10.9 14.6 lnb016m5b134ka90 130000 50*80 10.5 15.4 lnb016m5b134kc80 150000 35*105 9.7 16.5 lnb016m5b154kaa5 160000 50*90 8.7 13.5 lnb016m5b164kc90 160000 65*65 8.8 14.4 lnb016m6c164kd65 180000 35*115 8.8 15.3 lnb016m5b184kab5 200000 50*105 7.5 17.4 lnb016m5b204kca5 210000 35*130 8.2 17.5 lnb016m5b214kad0 220000 65*80 6.7 20.0 lnb016m6c224kd80 230000 35*140 7.8 19.3 lnb016m5b234kae0 230000 50*115 6.7 21.5 lnb016m5b234kcb5 260000 50*130 6.1 19.8 lnb016m5b264kcd0 270000 65*90 5.5 22.1 lnb016m6c274kd90 290000 50*140 5.7 22.9 lnb016m5b294kce0 320000 65*105 5.0 25.6 lnb016m6c324kda5 320000 76*80 4.2 28.9 lnb016m6c324ke80 380000 65*115 4.6 28.5 lnb016m6c384kdb5 400000 76*90 3.6 33.3 lnb016m6c404ke90 430000 65*130 4.4 27.9 lnb016m6c434kdd0 480000 76*105 3.3 33.8 lnb016m6c484kea5 490000 65*140 4.2 31.2 lnb016m6c494kde0 560000 76*115 3.1 37.5 lnb016m6c564keb5 650000 76*130 2.8 40.5 lnb016m6c654ked0 700000 89*105 2.9 41.6 lnb016m6c704kfa5 710000 76*140 2.8 42.8 lnb016m6c714kee0 750000 76*146 2.8 48.3 lnb016m6c754kee6 810000 89*115 2.8 42.1 lnb016m6c814kfb5 930000 89*130 2.5 46.2 lnb016m6c934kfd0 1000000 89*140 2.4 48.3 lnb016m6c105kfe0 1000000 76*192 2.6 47.5 lnb016m6c105kek2 1500000 89*192 2.3 55.4 lnb016m6c155kfk2 1700000 89*218 2.3 58.2 lnb016m6c175kfn8         25v 30sv 12000 35*40 37.1 4.7 lnb025m5b123ka40 20000 35*55 23.6 6.5 lnb025m5b203ka55 24000 35*65 20.1 7.5 lnb025m5b243ka65 33000 35*80 19.3 8.2 lnb025m5b333ka80 36000 35*55 21.8 8.2 lnb025m5b363ka55 42000 35*90 19.4 9.1 lnb025m5b423ka90 43000 35*65 19.4 9.5 lnb025m5b433ka65 47000 50*65 21.8 9.3 lnb025m5b473kc55 52000 35*105 17.6 10.7 lnb025m5b523kaa5 59000 50*65 16.5 9.0 lnb025m5b593kc65 60000 35*80 15.2 10.1 lnb025m5b603ka80 61000 35*115 16.4 10.3 lnb025m5b613kab5 71000 35*130 15.2 11.3 lnb025m5b713kad0 76000 50*80 12.2 13.2 lnb025m5b763kc80 77000 35*90 12.8 13.4 lnb025m5b773ka90 80000 35*140 14.0 13.3 lnb025m5b803kae0 90000 65*65 9.5 16.7 lnb025m6c903kd65 94000 35*105 10.2 14.2 lnb025m5b943kaa5 98000 50*90 9.8 13.6 lnb025m5b983kc90 110000 35*115 10.2 14.2 lnb025m5b114kab5 120000 50*105 8.3 16.6 lnb025m5b124kca5 130000 35*130 9.6 16.1 lnb025m5b134kad0 130000 65*80 7.6 18.9 lnb025m6c134kd80 140000 50*115 7.3 18.9 lnb025m5b144kcb5 150000 35*140 9.1 18.4 lnb025m5b154kae0 160000 50*130 6.6 19.1 lnb025m5b164kcd0 160000 65*90 6.4 20.5 lnb025m6c164kd90 190000 50*140 6.1 22.2 lnb025m5b194kce0 190000 76*80 5.0 25.5 lnb025m6c194ke80 200000 65*105 5.8 24.6 lnb025m6c204kda5 230000 65*115 5.2 26.8 lnb025m6c234kdb5 240000 76*90 4.3 30.5 lnb025m6c244ke90 270000 65*130 5.0 26.0 lnb025m6c274kdd0 300000 76*105 3.9 31.0 lnb025m6c304kea5 310000 65*140 4.6 29.8 lnb025m6c314kde0 350000 76*115 3.5 35.1 lnb025m6c354keb5 400000 76*130 3.3 37.5 lnb025m6c404ked0 430000 89*105 3.8 36.0 lnb025m6c434kfa5 460000 76*140 3.2 39.9 lnb025m6c464kee0 490000 76*146 3.1 46.0 lnb025m6c494kee6 500000 89*115 3.5 37.6 lnb025m6c504kfb5 580000 89*130 3.2 40.3 lnb025m6c584kfd0 660000 89*140 3.1 42.8 lnb025m6c664kfe0 670000 76*192 3.1 44.0 lnb025m6c674kek2 700000 89*146 2.9 44.9 lnb025m6c704kfe6 780000 76*218 3.0 44.9 lnb025m6c784ken8 950000 89*192 3.0 48.7 lnb025m6c954kfk2 1100000 89*218 2.9 51.1 lnb025m6c115kfn8 35v 40sv 8200 35*40 41.7 4.4 lnb035m5b822ka40 14000 35*55 26.7 6.1 lnb035m5b143ka55 16000 35*65 23.2 7.0 lnb035m5b163ka65 23000 35*80 21.9 7.7 lnb035m5b233ka80 25000 35*55 22.3 8.1 lnb035m5b253ka55 30000 35*90 21.6 8.6 lnb035m5b303ka65 30000 35*65 19.2 9.5 lnb035m5b303ka65 32000 50*55 24.5 8.8 lnb035m5b323kc55 36000 35*105 20.1 10.0 lnb035m5b363kaa5 41000 50*65 20.1 8.1 lnb035m5b413kc65 42000 35*80 15.5 10.0 lnb035m5b423ka80 43000 35*115 17.8 9.9 lnb035m5b433kab5 49000 35*130 15.5 11.2 lnb035m5b493kad0 53000 50*80 15.9 11.6 lnb035m5b533kc80 54000 35*90 13.2 13.2 lnb035m5b543ka90 56000 35*140 14.1 13.3 lnb035m5b563kae0 63000 65*65 14.8 13.4 lnb035m6c633kd65 66000 35*105 11.8 11.5 lnb035m5b663kaa5 69000 50*90 13.2 11.7 lnb035m5b693kc90 78000 35*115 10.6 13.9 lnb035m5b783kab5 84000 50*105 11.6 14.0 lnb035m5b843kca5 88000 65*80 11.5 14.7 lnb035m6c883kd80 90000 35*130 9.8 16.6 lnb035m5b903kad0 99000 50*115 10.5 16.6 lnb035m5b993kcb5 100000 35*140 9.4 18.1 lnb035m5b104kae0 110000 50*130 9.8 15.6 lnb035m5b114kcd0 110000 65*90 9.4 16.9 lnb035m6c114kd90 130000 50*140 9.4 17.9 lnb035m5b134kce0 130000 76*80 6.9 21.8 lnb035m6c134ke80 140000 65*105 8.2 20.6 lnb035m6c144kda5 160000 65*115 7.4 22.5 lnb035m6c164kdb5 170000 76*90 5.7 26.4 lnb035m6c174ke90 190000 65*130 6.8 22.3 lnb035m6c194kdd0 210000 65*140 6.1 24.7 lnb035m6c214kde0 210000 76*105 5.2 28.0 lnb035m6c214kea5 240000 76*115 4.5 30.5 lnb035m6c244keb5 280000 76*130 4.4 32.6 lnb035m6c284ked0 300000 89*105 4.9 31.7 lnb035m6c304kfa5 320000 76*140 4.0 35.5 lnb035m6c324kee0 340000 76*146 3.9 40.9 lnb035m6c344kee6 350000 89*115 4.5 33.0 lnb035m6c354kfb5 410000 89*130 4.0 36.2 lnb035m6c414kfd0 460000 89*140 3.6 39.2 lnb035m6c464kfe0 470000 76*192 3.8 39.8 lnb035m6c474kek2 490000 89*146 3.5 41.1 lnb035m6c494kfe6 550000 76*218 3.6 40.9 lnb035m6c554ken8 680000 89*192 3.4 45.7 lnb035m6c684kfk2 790000 89*218 3.3 48.4 lnb035m6c794kfn8 50v 65sv 5900 35*40 47.9 4.1 lnb050m5b592ka40 10000 35*55 30.9 5.6 lnb050m5b103ka55 12000 35*65 25.9 6.7 lnb050m5b123ka65 16000 35*80 23.6 7.4 lnb050m5b163ka80 18000 35*55 22.8 8.0 lnb050m5b193ka55 21000 35*90 19.6 9.0 lnb050m5b213ka90 21000 35*65 20.2 9.3 lnb050m5b213ka65 23000 50*55 25.3 8.6 lnb050m5b233kc55 26000 35*105 18.7 10.4 lnb050m5b263kaa5 29000 50*65 20.8 8.0 lnb050m5b293kc65 30000 35*80 15.6 9.9 lnb050m5b303ka80 31000 35*115 17.9 9.9 lnb050m5b313kab5 35000 35*130 15.9 11.0 lnb050m5b353kad0 38000 35*90 13.5 12.5 lnb050m5b383ka90 38000 50*80 16.3 11.9 lnb050m5b383kc80 40000 35*140 14.4 13.1 lnb050m5b403kae0 45000 65*65 14.4 13.1 lnb050m6c453kd65 47000 35*105 12.0 11.4 lnb050m5b473kaa5 49000 50*90 13.6 11.6 lnb050m5b493kc90 56000 35*115 10.8 13.8 lnb050m5b563kab5 60000 50*105 11.9 13.8 lnb050m5b603kca5 63000 65*80 12.0 14.4 lnb050m6c633kd80 64000 35*130 9.8 16.6 lnb050m5b643kad0 71000 50*115 10.8 16.4 lnb050m5b713kcb5 73000 35*140 9.5 18.0 lnb050m5b733kae0 81000 65*90 10.3 15.2 lnb050m6c813kd90 82000 50*130 10.0 16.4 lnb050m5b823kcd0 93000 50*140 9.5 17.7 lnb050m5b933kce0 94000 76*80 9.1 18.9 lnb050m6c943ke80 99000 65*105 8.9 19.8 lnb050m6c993kda5 120000 65*115 7.9 21.8 lnb050m6c124kdb5 120000 76*90 7.7 22.7 lnb050m6c124ke90 130000 65*130 7.2 21.7 lnb050m6c134kdd0 150000 65*115 6.7 23.7 lnb050m6c154kdb5 150000 76*105 6.9 24.2 lnb050m6c154kea5 170000 76*115 6.1 26.7 lnb050m6c174keb5 200000 76*130 5.9 28.1 lnb050m6c204ked0 200000 89*105 6.4 27.9 lnb050m6c204kfa5 230000 76*140 5.6 30.0 lnb050m6c234kee0 230000 89*115 5.7 33.8 lnb050m6c234kfb5 240000 76*146 5.4 30.2 lnb050m6c244kee6 270000 89*130 5.4 31.3 lnb050m6c274kfd0 310000 89*140 5.1 33.2 lnb050m6c314kfe0 320000 89*146 4.9 34.8 lnb050m6c324kfe6 350000 76*192 4.5 37.5 lnb050m6c354kek2 390000 76*218 4.1 38.6 lnb050m6c394ken8 450000 89*192 4.2 41.3 lnb050m6c454kfk2 520000 89*218 3.8 44.9 lnb050m6c524kfn8 63v 75sv 4100 35*40 60.6 3.6 lnb063m5b412ka40 7000 35*55 39.0 5.0 lnb063m5b702ka55 8300 35*65 32.7 5.9 lnb063m5b832ka65 12000 35*80 28.6 6.8 lnb063m5b123ka80 13000 35*55 27.9 7.2 lnb063m5b133ka55 15000 35*90 26.1 7.8 lnb063m5b153ka90 15000 35*65 25.6 8.2 lnb063m5b153ka65 15000 50*55 28.0 8.2 lnb063m5b153kc55 18000 35*105 22.0 9.6 lnb063m5b183kaa5 18000 50*65 22.6 7.7 lnb063m5b183kc65 21000 35*115 19.3 8.9 lnb063m5b213kab5 21000 35*80 19.5 9.4 lnb063m5b213ka80 25000 35*130 17.3 10.6 lnb063m5b253kad0 25000 50*80 18.1 10.8 lnb063m5b253kc80 27000 35*90 16.2 11.9 lnb063m5b273ka90 28000 35*140 15.8 12.5 lnb063m5b283kae0 29000 65*65 26.8 9.9 lnb063m6c293kd05 32000 50*90 15.1 10.2 lnb063m5b323kc90 33000 35*105 14.2 11.3 lnb063m5b333kaa5 39000 35*115 12.8 12.7 lnb063m5b393kab5 39000 50*105 13.3 13.1 lnb063m5b393kca5 41000 65*80 19.3 11.4 lnb063m6c413kd80 45000 35*130 11.8 15.1 lnb063m5b453kad0 46000 50*115 12.1 15.5 lnb063m5b463kcb5 51000 35*140 11.2 16.6 lnb063m5b513kae0 52000 65*90 17.1 11.8 lnb063m6c523kd90 53000 50*130 11.3 15.5 lnb063m5b533kcd0 60000 50*140 10.7 16.7 lnb060m5b603kce0 61000 76*80 14.9 14.8 lnb063m6c613ke80 64000 65*105 13.7 16.0 lnb063m6c643kda5 76000 65*115 11.8 17.8 lnb063m6c763kdb5 78000 76*90 12.1 18.1 lnb063m6c783ke90 87000 65*130 11.0 17.6 lnb063m6c873kdd0 95000 76*105 10.8 18.6 lnb063m6c953kea5 99000 65*140 10.5 19.7 lnb063m6c993kde0 110000 76*115 9.9 21.0 lnb063m6c114keb5 130000 76*130 8.8 23.0 lnb063m6c134ked0 130000 89*105 9.9 22.3 lnb063m6c134kfa5 150000 76*140 7.9 25.3 lnb063m6c154kee0 150000 89*115 9.0 26.8 lnb063m6c154kfb5 160000 76*146 7.5 25.5 lnb063m6c164kee6 180000 89*130 7.9 25.7 lnb063m6c184kfd0 200000 89*140 7.2 28.0 lnb063m6c204kfe0 210000 89*146 6.8 29.4 lnb063m6c214kfe6 230000 76*192 6.5 31.2 lnb063m6c234kek2 250000 76*218 5.7 32.6 lnb063m6c254ken8 300000 89*192 5.8 35.3 lnb063m6c304kfk2 350000 89*218 5.2 38.5 lnb063m6c354kfn8 75v 95sv 3200 35*40 76.2 3.2 lnb075m5b322ka40 5300 35*55 50.7 4.4 lnb075m5b532ka55 6400 35*65 41.7 5.2 lnb075m5b642ka65 9000 35*80 38.6 5.8 lnb075m5b902ka80 9900 35*55 55.6 5.1 lnb075m5b992ka55 12000 35*90 47.3 6.8 lnb075m5b123ka90 12000 35*65 34.8 7.4 lnb075m5b123ka65 12000 50*55 34.8 7.4 lnb075m5b123kc55 14000 35*105 30.5 8.1 lnb075m5b143kaa5 14000 50*65 27.5 6.9 lnb075m5b143kc65 16000 35*80 34.1 6..7 lnb075m5b163ka80 17000 35*115 26.2 8.2 lnb075m5b173kab5 19000 35*130 23.8 9.0 lnb075m5b193kad0 19000 50*80 21.4 10.0 lnb075m5b193kc80 21000 35*90 26.9 9.3 lnb075m5b213ka90 22000 35*140 21.4 10.8 lnb075m5b223kae0 23000 65*65 30.0 9.4 lnb075m6c233kd65 25000 50*90 18.0 9.3 lnb075m5b253kc90 26000 35*105 22.3 9.0 lnb075m5b263kaa5 30000 35*115 19.2 10.4 lnb075m5b303kab5 30000 50*105 15.6 12.1 lnb075m5b303kca5 32000 65*80 21.6 10.7 lnb075m6c323kd80 35000 35*130 16.9 12.6 lnb075m5b353kad0 35000 50*115 13.9 14.4 lnb075m5b353kcb5 40000 35*140 15.2 14.3 lnb075m5b403kae0 41000 50*130 12.8 13.7 lnb075m5b413kcd0 41000 65*90 17.8 12.3 lnb075m6c413kd90 46000 50*140 12.0 15.8 lnb075m5b463kce0 47000 76*80 18.0 13.4 lnb075m6c473ke80 50000 65*105 15.1 15.2 lnb075m6c503kda5 59000 65*115 13.5 16.7 lnb075m6c593kdb5 61000 76*90 14.4 16.6 lnb075m6c613ke90 68000 65*130 12.0 16.8 lnb075m6c683kdd0 74000 76*105 12.9 17.0 lnb075m6c743kes5 77000 65*140 11.2 19.0 lnb075m6c773kde0 88000 76*115 11.8 19.2 lnb075m6c883keb5 100000 76*130 10.4 21.1 lnb075m6c104ked0 100000 89*105 11.8 20.4 lnb075m6c104kfa5 110000 76*140 9.4 23.3 lnb075m6c114kee0 120000 76*146 8.9 26.9 lnb075m6c124kee6 120000 89*115 10.7 21.4 lnb075m6c124kfb5 140000 89*130 9.4 23.7 lnb075m6c144kfd0 160000 89*140 8.4. 25.7 lnb075m6c164kfe0 170000 76*190 7.7 28.1 lnb075m6c174kek2 170000 89*146 8.1 27.1 lnb075m6c174kfe6 200000 76*218 6.8 29.8 lnb075m6c204ken8 230000 89*192 6.9 32.3 lnb075m6c234kfk2 270000 89*218 6.2 35.2 lnb075m6c274kfn8 100v 125sv 1900 35*40 98.4 2.9 lnb100m5b192ka40 3100 35*55 60.2 4.0 lnb100m5b312ka55 3900 35*65 51.0 4.7 lnb100m5b392ka65 5500 35*80 43.4 5.5 lnb100m5b552ka80 6000 35*55 62.0 4.8 lnb100m5b602ka55 6300 50*55 51.8 5.6 lnb100m5b632kc55 7000 35*90 36.5 6.9 lnb100m5b702ka90 7100 35*65 52.8 6.0 lnb100m5b712ka65 8600 35*105 33.3 7.8 lnb100m5b862kaa5 9000 50*65 37.8 5.9 lnb100m5b902kc65 9900 35*80 38.0 6.4 lnb100m5b992kc80 10000 35*115 31.1 7.5 lnb100m5b103kab5 12000 35*130 30.0 8.0 lnb100m5b123kad0 13000 35*140 29.0 8.6 lnb100m5b133kae0 13000 35*90 29.9 8.8 lnb100m5b133ka90 13000 50*80 30.6 9.0 lnb100m5b133kc80 15000 65*65 33.7 8.9 lnb100m6c153kd65 16000 35*105 24.8 8.0 lnb100m5b163kaa5 16000 50*90 22.3 9.0 lnb100m5b163kc90 18000 35*115 21.2 9.8 lnb100m5b183kab5 20000 50*105 19.9 10.7 lnb100m5b203kca5 21000 35*130 18.7 11.5 lnb100m5b213kad0 21000 65*80 23.4 10.7 lnb100m6c213kd80 23000 50*115 17.7 12.8 lnb100m5b233kcb5 24000 35*140 16.8 13.6 lnb100m5b243kae0 27000 50*130 15.6 12.4 lnb100m5b273kcd0 27000 65*90 19.1 11.9 lnb100m6c273kd90 31000 50*140 14.9 14.1 lnb100m5b313kce0 31000 76*80 19.9 12.8 lnb100m6c313ke80 33000 65*105 16.5 14.6 lnb100m6c333kda5 39000 65*115 14.7 16.0 lnb100m6c393kdb5 40000 76*90 16.4 15.6 lnb100m6c403ke90 45000 65*130 13.4 15.9 lnb100m6c453kdd0 49000 76*105 14.4 16.1 lnb100m6c493kea5 51000 65*140 12.5 18.0 lnb100m6c513kde0 58000 76*115 13.0 18.3 lnb100m6c583keb5 67000 76*130 12.0 19.7 lnb100m6c673ked0 67000 89*105 13.4 19.2 lnb100m6c673kfa5 76000 76*140 11.2 21.3 lnb100m6c763kee0 79000 89*115 12.1 23.1 lnb100m6c793kfb5 80000 76*146 11.1 21.0 lnb100m6c803kee6 92000 89*130 10.9 22.0 lnb100m6c923kfd0 100000 89*140 10.2 23.4 lnb100m6c104kfe0 110000 76*192 9.2 25.8 lnb100m6c114kek2 110000 89*146 10.0 24.3 lnb100m6c114kfe6 130000 76*218 8.2 27.3 lnb100m6c134ken8 150000 89*192 8.3 29.5 lnb100m6c154kfk2 180000 89*218 7.3 32.3 lnb100m6c184kfn8 160v 200sv 1100 35*40 149.6 2.3 lnb160m5b112ka40 1800 35*55 93.0 3.3 lnb160m5b182ka55 2300 35*65 70.5 4.0 lnb160m5b232ka65 3200 35*80 58.5 4.7 lnb160m5b322ka80 3500 35*55 62.0 4.8 lnb160m5b352ka55 3700 50*55 70.5 4.8 lnb160m5b372kc55 4100 35*90 50.2 5.9 lnb160m5b412ka90 4100 35*65 42.9 6.9 lnb160m5b412ka65 5000 35*105 42.9 6.9 lnb160m5b502kaa5 5300 50*65 46.5 5.3 lnb160m5b532kc65 5800 35*80 38.0 6.4 lnb160m5b582ka80 5900 35*115 37.7 6.8 lnb160m5b592kab5 6800 35*130 34.7 7.5 lnb160m5b682kad0 7400 35*90 29.9 8.4 lnb160m5b742ka90 7400 50*80 33.5 8.3 lnb160m5b742kc80 7700 35*140 32.2 8.8 lnb160m5b772kae0 8300 65*65 30.1 9.4 lnb160m6c832kd65 9100 35*105 24.8 8.0 lnb160m5b912kaa5 9500 50*90 26.4 8.3 lnb160m5b952kc90 11000 35*115 21.2 9.8 lnb160m5b113kab5 12000 35*130 18.7 11.0 lnb160m5b123kad0 12000 50*105 21.9 10.7 lnb160m5b123kca5 12000 65*80 21.3 11.2 lnb160m6c123kd80 14000 35*140 16.8 12.8 lnb160m5b143kae0 14000 50*115 18.8 12.8 lnb160m5b143kcb5 15000 65*90 17.0 11.9 lnb160m6c153kd90 16000 50*130 16.6 12.8 lnb160m5b163kcd0 17000 76*80 14.7 14.3 lnb160m6c173ke80 18000 50*140 14.9 14.8 lnb160m5b183kce0 18000 65*105 14.1 15.8 lnb160m6c183kda5 22000 65*115 11.9 17.8 lnb160m6c223kdb5 22000 76*90 11.5 18.6 lnb160m6c223ke90 25000 65*130 10.7 17.8 lnb160m6c253kdd0 27000 76*105 9.6 19.7 lnb160m6c273kea5 28000 65*140 9.6 20.5 lnb160m6c283kde0 32000 76*115 8.2 23.0 lnb160m6c323keb5 37000 76*130 7.3 25.3 lnb160m6c373ked0 37000 89*105 9.2 23.2 lnb160m6c373kfa5 42000 76*140 6.5 27.9 lnb160m6c423kee0 44000 89*115 7.9 28.6 lnb160m6c443kfb5 45000 76*146 6.2 27.1 lnb160m6c453kee6 51000 89*130 6.9 27.5 lnb160m6c513kfd0 58000 89*140 6.2 30.0 lnb160m6c583kfe0 61000 89*146 5.9 31.6 lnb160m6c613kfe6 62000 76*192 5.1 34.9 lnb160m6c623kek2 72000 76*218 4.3 37.5 lnb160m6c723ken8 85000 89*192 4.9 38.8 lnb160m6c853kfk2 99000 89*218 4.2 42.8 lnb160m6c993kfn8   200v 250sv 680 35*40 205.8 2.0 lnb200m5b681ka40 1000 35*55 140.3 2.6 lnb200m5b102ka55 1500 35*65 100.5 3.4 lnb200m5b152ka65 1800 35*80 78.5 4.1 lnb200m5b182ka80 1900 35*55 79.1 4.3 lnb200m5b192ka55 2200 35*90 63.9 5.0 lnb200m5b222ka90 2400 35*65 62.5 5.3 lnb200m5b242ka65 2500 50*55 82.0 4.8 lnb200m5b252kc55 2700 35*105 51.7 6.2 lnb200m5b272kaa5 3100 35*80 48.4 5.2 lnb200m5b312ka80 3300 35*115 43.2 6.0 lnb200m5b332kab5 3300 50*65 61.0 5.3 lnb200m5b332kc65 3800 35*90 37.9 7.2 lnb200m5b382ka90 3900 35*130 37.8 7.5 lnb200m5b392kad0 4300 50*80 46.1 7.1 lnb200m5b432kc80 4500 35*140 33.4 8.6 lnb200m5b452kae0 4600 35*105 31.3 9.2 lnb200m5b462kaa5 5400 35*115 26.8 7.7 lnb200m5b542kab5 5500 65*65 42.2 6.6 lnb200m6c552kd65 5600 50*90 36.2 7.5 lnb200m5b562kc90 6100 35*130 23.5 9.9 lnb200m5b612kad0 6900 35*140 21.0 10.9 lnb200m5b692kae0 6900 50*105 28.5 9.7 lnb200m5b692kca5 7100 65*80 31.2 9.6 lnb200m6c712kd80 8200 50*115 24.4 11.2 lnb200m5b822kcb5 9100 50*130 21.7 10.5 lnb200m5b912kcd0 10000 50*140 19.6 11.7 lnb200m5b103kce0 10000 65*90 22.3 11.6 lnb200m6c103kd90 11000 65*105 20.3 12.7 lnb200m6c113kda5 11000 76*80 30.3 10.8 lnb200m6c113ke80 12000 65*115 17.3 14.7 lnb200m6c123kdb5 13000 65*130 15.8 15.9 lnb200m6c133kdd0 13000 76*90 23.7 12.0 lnb200m6c133ke90 15000 65*140 13.7 16.5 lnb200m6c153kde0 15000 76*105 19.7 14.3 lnb200m6c153kea5 18000 76*115 16.9 16.1 lnb200m6c183keb5 21000 89*105 17.1 16.5 lnb200m6c213kfa5 22000 76*130 14.8 18.2 lnb200m6c223ked0 24000 76*140 13.3 19.5 lnb200m6c243kee0 25000 89*115 15.3 20.5 lnb200m6c253kfb5 26000 76*146 12.7 19.7 lnb200m6c263kee6 28000 89*130 13.4 19.8 lnb200m6c283kfd0 31000 89*140 12.0 21.6 lnb200m6c313kfe0 33000 76*192 10.8 23.7 lnb200m6c333kek2 33000 89*146 11.5 22.7 lnb200m6c333kfe6 37000 76*218 9.6 25.2 lnb200m6c373ken8 44000 89*192 9.3 28.2 lnb200m6c443kfk2 51000 89*218 7.9 31.1 lnb200m6c513kfn8 250v 300sv 470 35*40 259.7 1.8 lnb250m5b471ka40 820 35*55 156.4 2.5 lnb250m5b821ka55 1200 35*65 118.7 3.1 lnb250m5b122ka65 1400 35*55 99.0 3.6 lnb250m5b142ka55 1500 35*80 88.0 4.1 lnb250m5b152ka80 1800 35*65 83.3 4.4 lnb250m5b182ka65 1800 50*55 94.7 4.3 lnb250m5b182kc55 1900 35*90 69.5 5.2 lnb250m5b192ka90 2300 35*105 57.9 5.9 lnb250m5b232kaa5 2300 35*80 61.3 4.6 lnb250m5b232ka80 2400 35*115 51.4 5.5 lnb250m5b242kab5 2500 50*65 65.7 5.2 lnb250m5b252kc65 2700 35*130 48.7 6.6 lnb250m5b272kad0 3000 35*90 48.7 6.6 lnb250m5b302ka90 3300 50*80 46.2 7.1 lnb250m5b331kc80 3400 35*140 38.3 8.0 lnb250m5b342kae0 3700 35*105 40.5 8.1 lnb250m5b372kaa5 3900 35*115 34.8 6.7 lnb250m5b392kab5 3900 50*90 38.2 6.9 lnb250m5b392kc90 4100 65*65 51.8 6.3 lnb250m6c412kd65 4500 35*130 30.6 8.6 lnb025m5b452kad0 4700 50*105 31.5 8.9 lnb250m5b472kca5 5000 35*140 27.3 9.9 lnb250m5b502kae0 5200 65*80 32.1 9.5 lnb250m6c522kd80 5600 50*115 26.9 10.7 lnb250m5b562kcb5 6200 50*130 23.6 10.1 lnb250m5b622kcd0 6400 65*90 25.1 10.4 lnb250m6c642kd90 6800 50*140 21.2 11.9 lnb250m5b682kce0 7800 76*80 27.6 10.9 lnb250m6c782ke80 8200 65*105 20.8 13.0 lnb250m6c822kda5 10000 65*115 17.8 14.5 lnb250m6c103kdb5 10000 76*90 21.6 13.6 lnb250m6c103ke90 11000 65*130 15.5 14.8 lnb250m6c113kdd0 12000 65*140 13.8 16.5 lnb250m6c123kde0 12000 76*105 17.6 15.2 lnb250m6c123kea5 13000 76*115 16.3 16.4 lnb250m6c133keb5 15000 76*130 14.3 18.0 lnb250m6c153ked0 16000 89*105 19.5 15.9 lnb250m6c163kfa5 18000 76*140 12.0 20.6 lnb250m6c183kee0 18000 89*115 17.1 19.4 lnb250m6c183kfb5 19000 76*146 11.5 20.6 lnb250m6c193kee6 21000 89*130 15.1 18.7 lnb250m6c213kfd0 23000 89*140 13.4 20.4 lnb250m6c233kfe0 24000 89*146 12.9 21.4 lnb250m6c243kfe6 27000 76*192 9.5 27.2 lnb250m6c273kek2 30000 76*218 7.0 29.6 lnb250m6c303ken8 33000 89*192 10.6 26.2 lnb250m6c333kfk2 38000 89*218 9.2 28.8 lnb250m6c383kfn8 300v 350sv 330 35*40 418.1 1.4 lnb300m5b331ka40 600 35*55 231.4 2.1 lnb300m5b601ka55 730 35*65 188.8 2.5 lnb300m5b731ka65 1000 35*80 137.5 3.1 lnb300m5b102ka80 1000 35*55 139.3 3.2 lnb300m5b102ka55 1200 35*65 117.2 3.7 lnb300m5b122ka65 1200 50*55 131.1 3.6 lnb300m5b122kc55 1300 35*90 106.8 4.2 lnb300m5b132ka90 1500 35*105 90.4 4.7 lnb300m5b152kaa5 1500 50*65 102.6 3.6 lnb300m5b152kc65 1700 35*80 84.5 4.3 lnb300m5b172ka80 1800 35*115 77.4 4.7 lnb300m5b182kab5 2100 35*130 65.7 5.4 lnb300m5b212kad0 2100 35*90 68.3 5.6 lnb300m5b212ka90 2200 50*80 71.1 5.7 lnb300m5b222kc80 2300 35*140 60.3 6.4 lnb300m5b232kae0 2600 35*105 56.7 6.8 lnb300m5b262kaa5 2600 65*65 60.5 5.1 lnb300m6c262kd65 2800 50*90 55.5 5.7 lnb300m5b282kc90 3000 35*115 48.5 6.5 lnb300m5b302kab5 3300 65*80 46.5 7.0 lnb300m6c332kd80 3400 50*105 45.7 7.4 lnb300m5b342kca5 3500 35*130 42.5 8.0 lnb300m5b352kad0 3900 35*140 37.9 8.7 lnb300m5b392kae0 4000 50*115 38.9 8.9 lnb300m5b402kcb5 4200 65*90 38.1 7.9 lnb300m6c422kd90 4600 50*130 34.0 8.9 lnb300m5b462kcd0 4800 76*80 42.8 8.4 lnb300m6c482ke80 5200 65*105 29.9 10.4 lnb300m6c522kda5 5300 50*140 30.2 10.8 lnb300m5b532kce0 6000 76*90 34.0 10.5 lnb300m6c602ke90 6100 65*115 25.5 12.5 lnb300m6c612kdb5 7100 65*130 22.2 12.3 lnb300m6c712kdd0 7400 76*105 26.2 11.9 lnb300m6c742kea5 8000 65*140 19.8 14.3 lnb300m6c802kde0 8700 76*115 23.6 13.6 lnb300m6c872keb5 10000 76*130 20.5 15.1 lnb300m6c103ked0 10000 89*105 21.0 15.3 lnb300m6c103kfa5 11000 76*140 18.0 16.8 lnb300m6c113kee0 12000 76*146 17.0 19.5 lnb300m6c123kee6 12000 89*115 18.2 16.4 lnb300m6c123kfb5 13000 89*130 16.0 18.1 lnb300m6c133kfd0 15000 89*140 14.3 19.8 lnb300m6c153kfe0 16000 76*192 13.2 21.8 lnb300m6c163kek2 16000 89*146 13.5 20.9 lnb300m6c163kfe6 19000 76*218 10.8 23.7 lnb300m6c193ken8 22000 89*192 11.0 25.9 lnb300m6c223kfk2 26000 89*218 9.3 28.6 lnb300m6c263kfn8 350v 400sv 220 35*40 605.4 1.2 lnb350m5b221ka40 430 35*55 378.5 1.6 lnb350m5b431ka55 510 35*65 253.0 2.1 lnb350m5b511ka65 680 35*80 190.2 2.6 lnb350m5b681ka80 760 35*55 176.6 2.9 lnb350m5b761ka55 860 35*90 152.5 3.2 lnb350m5b861ka90 920 35*65 161.7 3.3 lnb350m5b921ka65 990 50*55 167.6 3.3 lnb350m5b991kc55 1000 35*105 127.5 4.0 lnb350m5b102kaa5 1200 35*115 109.6 3.5 lnb350m5b122kab5 1200 35*80 124.7 3.5 lnb350m5b122ka80 1200 50*65 132.2 3.6 lnb350m5b122kc65 1300 35*130 97.2 4.5 lnb350m5b132kad0 1500 35*140 85.9 5.0 lnb350m5b152kae0 1500 35*90 97.3 4.9 lnb350m5b152ka90 1500 50*80 101.5 4.9 lnb350m5b152kc80 1800 35*105 79.9 5.8 lnb350m5b182kaa5 1900 50*90 79.2 4.4 lnb350m5b192kc90 2000 65*65 86.9 4.6 lnb350m6c202kd65 2100 35*115 67.8 5.5 lnb350m5b212kab5 2300 50*105 65.1 5.9 lnb350m5b232kca5 2400 35*130 59.1 6.5 lnb350m5b242kad0 2500 65*80 61.0 6.6 lnb350m6c252kd80 2700 35*140 52.4 7.4 lnb350m5b272kae0 2700 50*115 55.4 7.5 lnb350m5b272kcb5 3100 50*130 48.7 7.0 lnb350m5b312kcd0 3100 65*90 48.5 7.5 lnb350m6c312kd90 3500 50*140 42.8 8.3 lnb350m5b352kce0 3700 65*105 39.9 9.0 lnb350m6c372kda5 3800 76*80 54.0 8.1 lnb350m6c382ke80 4200 65*115 34.0 10.5 lnb350m6c422kdb5 4600 76*90 41.7 9.8 lnb350m6c462ke90 4800 65*130 29.6 10.7 lnb350m6c482kdd0 5400 65*140 26.2 11.9 lnb350m6c542kde0 5500 76*105 34.7 10.8 lnb350m6c552kea5 6300 76*115 29.6 12.2 lnb350m6c632keb5 7200 76*130 25.8 13.4 lnb350m6c722ked0 7700 89*105 29.9 12.8 lnb350m6c772kfa5 8200 76*140 22.9 14.9 lnb350m6c822kee0 8400 76*146 21.7 17.2 lnb350m6c842kee6 8800 89*115 25.7 13.8 lnb350m6c882kfb5 10000 89*130 22.5 15.3 lnb350m6c103kfd0 11000 76*192 17.1 19.1 lnb350m6c113kek2 11000 89*140 20.0 16.7 lnb350m6c113kfe0 12000 89*146 18.9 17.7 lnb350m6c123kfe6 13000 76*218 14.2 20.7 lnb350m6c133ken8 16000 89*192 14.9 22.3 lnb350m6c163kfk2 18000 89*218 12.4 24.8 lnb350m6c183kfn8 400v 450sv 180 35*40 652.4 1.1 lnb400m5b181ka40 350 35*55 408.2 1.6 lnb400m5b351ka55 420 35*65 272.6 2.1 lnb400m5b421ka65 570 35*80 204.8 2.5 lnb400m5b571ka80 630 35*55 189.5 2.8 lnb400m5b631ka55 710 35*90 164.3 3.1 lnb400m5b711ka90 760 35*65 173.7 3.2 lnb400m5b761ka65 820 50*55 179.3 3.2 lnb400m5b821kc55 850 35*105 137.3 3.8 lnb400m5b851kaa5 1000 35*115 118.0 3.4 lnb400m5b102kab5 1000 35*80 134.0 3.4 lnb400m5b102ka80 1000 50*65 141.7 3.5 lnb400m5b102kc65 1100 35*130 104.6 4.6 lnb400m5b112kad0 1200 35*140 92.4 4.8 lnb400m5b122kae0 1200 35*90 106.6 4.6 lnb400m5b122ka90 1300 50*80 108.9 4.8 lnb400m5b132kc80 1500 35*105 85.8 5.6 lnb400m5b152kaa5 1600 50*90 85.0 4.3 lnb400m5b162kc90 1700 35*115 74.3 4.9 lnb400m5b172kab5 1700 65*65 93.1 4.7 lnb400m6c172kd65 1900 50*105 69.8 5.7 lnb400m5b192kca5 2000 35*130 63.4 6.3 lnb400m5b202kad0 2100 65*80 65.3 6.4 lnb400m6c212kd80 2200 35*140 57.3 7.1 lnb400m5b222kae0 2300 50*115 59.3 7.2 lnb400m5b232kcb5 2600 50*130 52.2 6.8 lnb400m5b262kcd0 2600 65*90 52.0 7.2 lnb400m6c262kd90 2900 50*140 45.9 8.1 lnb400m5b292kce0 3100 65*105 42.8 8.7 lnb400m6c312kda5 3200 76*80 57.5 7.8 lnb400m6c322ke80 3900 65*115 35.6 10.3 lnb400m6c392kdb5 3900 76*90 44.9 9.4 lnb400m6c392ke90 4000 65*130 31.7 10.3 lnb400m6c402kdd0 4700 65*140 28.1 11.5 lnb400m6c472kde0 4700 76*105 37.0 10.5 lnb400m6c472kea5 5300 76*115 31.5 11.8 lnb400m6c532keb5 6000 76*130 27.4 13.0 lnb400m6c602ked0 6400 89*105 31.9 12.4 lnb400m6c642kfa5 6800 76*140 24.4 14.4 lnb400m6c682kee0 7100 76*146 23.1 16.7 lnb400m6c712kee6 7400 89*115 27.4 13.4 lnb400m6c742kfb5 8400 89*130 23.9 14.8 lnb400m6c842kfd0 9400 89*140 21.2 16.2 lnb400m6c942kfe0 9600 76*192 18.2 18.6 lnb400m6c962kek2 9900 89*146 20.1 17.2 lnb400m6c992kfe6 11000 76*218 15.1 20.1 lnb400m6c113ken8 13000 89*192 15.8 21.7 lnb400m6c133kfk2 15000 89*218 13.1 24.1 lnb400m6c153kfn8 450v 500sv 150 35*40 796.7 1.0 lnb450m5b151ka40 270 35*55 437.7 1.5 lnb450m5b271ka55 350 35*65 337.1 1.8 lnb450m5b351ka65 460 35*55 264.2 2.2 lnb450m5b461ka55 470 35*80 253.2 2.4 lnb450m5b471ka80 560 35*90 203.0 2.8 lnb450m5b561ka90 570 35*65 213.1 2.9 lnb450m5b571ka65 590 50*55 228.4 2.9 lnb450m5b591kc55 680 35*105 169.5 3.4 lnb450m5b681kaa5 740 35*80 164.5 2.8 lnb450m5b741ka80 780 50*65 178.0 2.9 lnb450m5b781kc65 820 35*115 145.6 3.5 lnb450m5b821kab5 920 35*90 130.9 3.8 lnb450m5b921ka90 930 35*130 127.7 4.1 lnb450m5b931kad0 1000 35*140 113.9 4.5 lnb450m5b102kae0 1000 50*80 137.0 4.3 lnb450m5b102kc80 1100 35*105 107.4 5.0 lnb450m5b112kaa5 1200 50*90 109.0 3.8 lnb450m5b122kc90 1200 65*65 115.8 4.0 lnb450m6c122kd65 1300 35*115 91.1 4.7 lnb450m5b132kab5 1500 35*130 79.2 5.4 lnb450m5b152kad0 1500 50*105 89.5 5.3 lnb450m5b152kca5 1700 35*140 70.2 6.2 lnb450m5b172kae0 1700 65*80 81.1 6.0 lnb450m6c172kd80 1800 50*115 76.0 6.4 lnb450m5b182kcb5 1900 50*130 66.8 6.0 lnb450m5b192kcd0 2000 65*90 66.5 6.4 lnb450m6c202kd90 2200 50*140 58.6 7.1 lnb450m5b222kce0 2400 65*105 54.7 7.7 lnb450m6c242kda5 2500 76*80 65.7 7.3 lnb450m6c252ke80 2800 65*115 46.4 9.0 lnb450m6c282kdb5 3000 76*90 52.2 8.7 lnb450m6c302ke90 3300 65*130 40.4 9.2 lnb450m6c322kdd0 3900 65*140 35.4 10.3 lnb450m6c392kde0 3900 76*105 40.1 10.1 lnb450m6c392kea5 4100 76*115 37.5 10.8 lnb450m6c412keb5 4700 76*130 32.5 12.0 lnb450m6c472ked0 5000 89*105 31.8 12.5 lnb450m6c502kfa5 5600 76*140 28.8 13.3 lnb450m6c562kee0 5800 76*146 27.3 15.4 lnb450m6c582kee6 5800 89*115 27.0 13.5 lnb450m6c582kfb5 6800 89*130 23.5 15.0 lnb450m6c682kfd0 7300 89*140 21.1 16.3 lnb450m6c732kfe0 7700 89*146 20.0 17.2 lnb450m6c772kfe6 7900 76*192 21.3 17.1 lnb450m6c792kek2 9000 76*218 17.6 18.6 lnb450m6c902ken8 10000 89*192 15.9 21.6 lnb450m6c103kfk2 12000 89*218 13.3 24.0 lnb450m6c123kfn8 500v 550sv 110 35*40 1224.3 0.8 lnb500m5b111ka40 180 35*55 736.9 1.2 lnb500m5b181ka55 240 35*65 556.4 1.4 lnb500m5b241ka65 270 35*55 498.4 1.6 lnb500m5b271ka55 320 35*80 409.7 1.9 lnb500m5b321ka80 340 50*55 393.1 2.0 lnb500m5b341kc55 380 35*65 347.2 2.2 lnb500m5b381ka65 400 35*90 338.1 2.4 lnb500m5b401ka90 470 50*65 273.9 2.7 lnb500m5b471kc65 480 35*105 293.2 2.1 lnb500m5b481kaa5 500 35*80 264.5 2.4 lnb500m5b501ka80 560 35*115 261.2 2.6 lnb500m5b561kab5 640 35*130 231.1 2.9 lnb500m5b641kad0 650 35*90 202.0 3.2 lnb500m5b651ka90 700 50*80 200.1 3.4 lnb500m5b701kc80 720 35*140 195.4 3.6 lnb500m5b721kae0 790 35*105 172.4 3.9 lnb500m5b791kaa5 800 65*65 170.6 3.0 lnb500m6c801kd65 860 50*90 159.1 3.4 lnb500m5b861kc90 930 35*115 149.1 3.7 lnb500m5b931kab5 1000 550*105 138.7 4.1 lnb500m5b102kca5 1100 35*130 129.6 4.4 lnb500m5b112kad0 1100 65*80 122.0 4.7 lnb500m6c112kd80 1200 35*140 114.7 5.0 lnb500m5b122kae0 1200 50*115 117.7 5.1 lnb500m5b122kcb5 1400 50*130 102.3 4.8 lnb500m5b142kcd0 1400 65*90 95.1 5.3 lnb500m6c142kd90 1500 50*140 93.3 5.7 lnb500m5b152kce0 1700 65*105 79.7 6.4 lnb500m6c172kda5 1700 76*80 86.4 6.4 lnb500m6c172ke80 2100 65*130 61.1 7.8 lnb500m6c212kdd0 2200 65*115 68.3 7.6 lnb500m6c222kdb5 2200 76*90 67.4 7.1 lnb500m6c222ke90 2500 65*140 54.7 8.3 lnb500m6c252kde0 2500 76*105 55.4 8.6 lnb500m6c252kea5 3000 76*115 48.1 9.5 lnb500m6c302keb5 3400 76*130 43.1 10.4 lnb500m6c342ked0 3500 89*105 40.1 11.1 lnb500m6c352kfa5 3900 76*140 37.5 11.6 lnb500m6c392kee0 4100 76*146 35.5 13.5 lnb500m6c412kee6 4100 89*115 34.1 12.0 lnb500m6c412kfb5 4800 89*130 30.0 13.2 lnb500m6c482kfd0 5400 89*140 28.0 14.2 lnb500m6c542kfe0 5700 89*146 26.0 15.1 lnb500m6c572kfe6 5700 76*192 27.9 15.0 lnb500m6c572kek2 6600 76*218 23.1 16.2 lnb500m6c662ken8 7900 89*192 20.5 19.1 lnb500m6c792kfk2 9200 89*218 16.7 21.4 lnb500m6c922kfn8 550v 600sv 1400 65*105 170.5 4.9 lnb550m6c142kda5 1700 65*115 132.6 5.9 lnb550m6c172kdb5 1900 65*130 111.7 6.8 lnb550m6c192kdd0 2200 76*105 90.4 7.8 lnb550m6c222kea5 2300 65*140 86.5 7.8 lnb550m6c232kde0 2500 76*115 79.6 8.4 lnb550m6c252keb5 2900 76*130 64.0 9.7 lnb550m6c292ked0 3400 76*140 54.6 10.9 lnb550m6c342kee0 3700 76*146 50.2 12.2 lnb550m6c372kee6 5100 76*192 36.4 16.2 lnb550m6c512kek2

rted ripple current muiers
the ripple frequency and standard list of the specified value is not at the same time, please use the value is less than the following
●   frequency multiplier

frequency（hz）	50	120	300	1k	3k
coefficient	0.8	1.0	1.1	1.3	1.4

note : the endurance of capacitors is shorted with internal heating produced by ripple current at the rate of halving the lifetime with every 5 to 10℃ rise. when long life performance is required in actual use, the rms ripple current has to be reduced. also, for the lb series capacitors, using them at operating voltage less than their rated voltage can extend their lifetime. for the details, please contact representative of capsun
